How To Choose a Entry Level Digital Label Printing Machine

IQ330 is the ideal entry level digital label machine for some label printing factories with flexo printers , wine or food producers ,daily cosmetics products suppliers and so on. The machine can also be used as the label printing proof machine.

Here are some information for you to choose the machine you need:

A few points of interest: What is the maximum printing speed in meters per hour for printing + cutting?

A: cutting is much faster than printing, so speed is determined by printing. 4 pass at 56m/hour, 6 pass at 40m/hour, 8 pass at 28m/hour, it is an entry level printing machine suitable for low volume. it can print CMYK, plus white, plus varnish. 6 color. (for example, if machine works 10 hour a day, it can print 100 sqm/day, then 10000 labels for 10cmX10cm size labels for 10 hours.)

Are you able to print white on this machine and then over the white in color? This so we can print on transparent material without the printed color becoming transparent.

A:yes. in one run, the machine cans print white first, then following with CMYK printing.

The machine can do cold foil stamping. With what speed can it do this?

A: Foil stamping speed 56m/hour. It is digital cold foil stamping, varnishing first and then stamping foiling with substrate, the varnished area will stick foil, then peel off unvarnished area. Roller will add some heat to varnish, melting it then stick foils. It is digital, not traditional foil stamping.

The brochure talks about 2 die-cutting heads. What kind of cutting is included, is this using (semi)-rotary die cutting or uses a movable cutting knife.

A: It is digital die cutting, using movable cutting knife. standard configuration includes 2 cutting heads, optional can add 2 more heads to increase speed.

On cost consumption, say 1 sqm area, 50% area full pruning cmyk plus white, the total ink consumption is 5 ml, us55/1000 ml, so ink cost total for 1 sqm area is us$0.275 for CMYK plus white. . (50% area printing).If you have 10cmx10 cm label, then 1 sqm include 100 labels, then each label cost us0.275/100= us0.00275 each label for ink cost.

The machine's maximum capacity is determined by its printing speed. Post-processing enhancements include lamination and die-cutting, with speeds exceeding printing speeds. At a printing speed of 28 MB/hour, it can print 10 square meters per hour. Working 10 hours a day, it can print 100 square meters per day. Taking a single 10cm x 10cm label as an example,it can produce 10,000 labels per day, totaling 200,000-250,000 labels per month.
