Digital Label Printing Embellishment Machine Varnishing And Foiling

Digital Label Printing Embellishment Machine Varnishing And Foiling

EcooSpark is the digital roll to roll label UV Varnishing and Cold Foiling machine. It is the ideal post press digital embellishment machine for digital label printing machine such as HP Indigo,Xeikon,KM or Screen Truepress.Reliable performance and perfect effect.

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

Products Description

Digital Label Printing Embellishment Machine Varnishing and Foiling

Digital embellishment can make labels more attractive

A variety of digital label printing and post-press finishing equipment enables the production of diverse label products.The different labels can be printed and finished in short time with lower cost and waste. And the labels with different decorations such as gloss varnish,matt varnish,foiling,embossing can more easily catch customers' attention.

EcooSpark is the standalone Digital Roll to Roll Label Sticker Varnishing and Cold Foiling embellishment machine,developed and produced by leading OEM factory EcooGraphix in China. The laminating unit and extra corona treatment unit are optional for some special wine paper or PP film materials. Max print width is up to 450mm. And the variable data and tactile warning triangle,braille printing can also be made by this machine.

It is the ideal digital label post press embellishment machine for digital printer HP Indigo,Screen Truepress , Xeikon or other similars.

Applications

Wine Labels, Cosmetic Labels, Luxury labels ,Washi Tape ,Stickers ,Medical Labels ,Pouch Packages ,Braille Marks and so on.

Unlimited design ,
Fast setup time,
Automatic varnish ink cleaning ,
Varnish consumption data
Options of laminating or flexo coating

EcooGraphix EcooSpark DS288 Digital Label Foil Stamping and Varnishing Machine
Model DigiSpark
Printing Technology	UV Piezo DoD-inkjet
Resolution	up to 1440*360 dpi
Printing speed	10m/min - 60m/min(depend on polymer layer thickness)
Variable Image system	PDF, optimized PDF, Optional barcode system
Supported image standards	PDF,PDF/VT,TIFF, JPEG, BMP & other data base files
Substrates	Offset, Digital, Plastics, Laminated and coated substrates
Printing image width	288mm (extendable to 430 mm)
Polymer	WB-DS-Clear Polymer
Polymer layer thickness	From 10 up to 180 microns
Ink curing	Inter UV-LED Pre-curing/Full curing by UV-LED
Unwinder diameter	Max. 700mm, Core 76mm
Rewinder diameter	Max. 700mm, Core 76mm
Substrates thickness	30-400 micro
Substrates width	330mm
Press with Foil station dimensions (LxHxW)	3500mmx1900mmx1800mm
Operating environment	Temperature: 15℃-30℃, Humidity: 40%-80% relative humidity
Electrical requirements	Voltage: 3x380, ±5% 3 phases +G+N Frequency: 50/60 Hz Current: Avg. 25 Amps in Production
Weight	2800kg

20250925121020166267

Features

1)Full Sets of Mitsubishi servers;

2)HeFeng Corona Treatment;

3)Web guide and Monitoring System: E+L;

4) Full Led-UV curing system;

5) Printing Software: GIS UK;

6)Auto Cleaning System;

7) KM 1024i print head;

8) Multiple sensors for tention control.

Customizable

20251106143749413280

Company Profile

EcooGraphix is a leading global supplier and OEM factory of digital printing and packaging equipment and supplies. It began in 2010, developing and manufacturing CTP machines and printing plates.

Our team has 25 years of experience
EcooSetter CTP machines and Ecoo printing plates have now become globally renowned brands
Currently, there are over 500 printers worldwide running EcooGraphix CTP and printing plates daily.
The digital label printing is a new and fast growth .
Approximately 45 international distributors worldwide collaborate with EcooGraphix.
