Double Layer Thermal Solvent Resistant CTP Plate
EcooGraphix ECOO-TSR Thermal Solvent Resistance CTP plate can be used for long runs high grade offset commercial, packaging or newspaper printing. It is compatible with ordinary ink and UV ink with extra Long printing runlength and perfect performance.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
EcooGraphix Two Layer Thermal CTP plate ECOO-TSR
1.Application
EcooGraphix ECOO-TSR Thermal Solvent Resistance CTP plate can be used for long runs high grade offset commercial, packaging or newspaper printing. It is compatible with ordinary ink and UV ink with extra Long printing runlength and perfect performance.
2.Characteristic
Through a newly developed two-layer coating technology, ECOO-TSR plate brings exceptional quality and long run press performance without the need for post baking.
lt delivers high resolution and precise tone reproduction in the most demanding press conditions, such as UV ink and alcohol substitute founts. The state of the art technology also provides wide processing latitude to achieve excellent stability and FM imaging capability.
3.Specification
General Information | |
Plate Model | ECOO-TSR |
Plate Type | Positive Working Thermal CTP Plate(Double Layer) |
Application | High grade offset commercial ,packaging or newspaper printing |
Substrate | Electro chemically Grained and Anodized lithographic Aluminum |
Plate Thickness | 0.15,0.20, 0.25,0.30, 0.40 (mm) |
Maximum short grain width | Maximum width 1325 mm |
Plate intermix | Kodak Electra Excel HRL/HRO Thermal Plates, Kodak Sword |
Length of Press Runs | Ordinary Ink: 200,000 to 400,000 impressions unbaked UV Ink : 50,000 to 100,000 impressions |
Exposing | |
CTP Plate Making Machine Plate setters | Kodak: Trendsetter/Lotem/Magnus; Fuji : Javelin T9000HS Screen : PT-R,Creo : Scitex ;EcooGraphix Thermal CTP Tseries |
Exposure energy | 120 - 150 mj/cm² |
Spectral Sensitivity | 800-850 nm – Peaks 830nm |
Resolution | 1-99% at 400 LPI or FM 10 micron stochastic |
Image color | Blue |
Developing | |
Developer | Kodak Gold Star or EcooGraphix DV-T developer |
Processing temperature | 25°C +/- 3°C |
Developing time | 25+/- 5 sec |
Processing Speed | 0.80 – 1.20 m/min |
Storage and handling | |
Safelight | Daylight handling |
Shelf Life | 12 months under recommended storage conditions |
Storage and handling | Stored in a cool and dry environment, away from excessive cold, heat and humidity. |
CTP model Data | Kodak trendsetters | LOTTEM 400(TH1.7) | MAGNUS 400 | Screen 8600S |
Laser power | 15-17W | 300-320mw | 19.5-21.5W | 80-90 % |
Drum speed | 250-300rpm | 850-900rpm | 400-450rpm | 800-900rpm |
Resolution | Customized | Customized | Customized | Customized |
Parameter that need set up | Focus／ Zoom | Focus／ Zoom | Focus／ Zoom | Focus／ Zoom |
ECOO-TSR has a wide range of exposure energy, the range is 120-150mj/cm2, and the dot gain percentage is not much different within this range.
*Note: Higher exposure energy will make the image contrast more clear, and benefit to the plate run length; while over high/low exposure energy will affect the image quality negatively.
Production Lines and Quality Control
● First class and brand new international production facility. 35 meters per minute line achieves high productivity.
● 3 steps of quality control systems: constant online digital inspection system, constant online worker selective examination, 100% manual inspection
● Stringent quality standard: Plate thickness, cutting quality, packaging quality strictly complying with ISO 9000 standard and strictly complying with product parameters.
● Best quality raw material:
● Aluminum: only use South Western Aluminum, Best quality aluminum roll manufacturer. This ensures the plate substrate quality.
● Coating emulsion: use imported international top quality emulsion
FAQ
Q1: Can I get the sample?
A: We are very glad to provide some sample for you to test. We usually provide 5-20pieces plates for free.
Q2: What is the cost for the CTP plate sample freight?
A: The Air freight depends on the packing size and weight, and the delivery destination. Or you can arrange the Pick-up service from your local agent.
Q3: How long can the sample be ready?
A: It usually takes about 5days to prepare the sample.
Q4: Can I visit your factory?
A: You are warmly welcomed to visit our factory! Our company is in Hangzhou city, which is about 1.5 hour by train from Shanghai.
EcooGraphix Developer and Replenisher
CTP Developer(DV-T) | |
Application | Development Thermal CTP Plate |
Specialty | Stable Performance and rapid development |
Good Protection to both image and non-image area | |
Less harmful to photosensitive layer and oxide layer | |
Fast Processing speed with sharp dots and clean background | |
Replenishment | 120ml/㎡ |
Static | 60ml/h |
Packing | 20L/drum |
CTP Replenisher (DV-T+1) | |
Application | Development Thermal CTP Plate |
Specialty | Stable Performance and rapid development |
Good Protection to both image and non-image area | |
Less harmful to photosensitive layer and oxide layer | |
Fast Processing speed with sharp dots and clean background | |
Replenishment | 120ml/㎡ |
Static | 60ml/h |
Packing | 20L/drum |
