60Plates/Hour News Thermal CTP PlateSetter
Newspaper Use Thermal Ctp Plate Making Machine
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
1200DPI 60PPH T-800F News Thermal CTP PlateSetter
EcooGraphix T-800F News Thermal CTP Ensures Your Headlines Go to Print On Time, Every Time
With 60PPH high speed and newspaper-grade precision, this design redefines prepress efficiency for medium to large publications.
Model: EcooSetter T-800F News
o(´^｀)o Technical Specifications
ECOO T-800F News Thermal CTP Specifications
Model
T-800F News
Exposing Method
External drum
Imaging System
64-channel,
Discrete 830nm laser diode
Throughput
60 plates/hour
381mm x 578mm, 1200dpi
Plate Size
Max. 1130mm x 920mm, Min. 300mm x 260mm
Media Type
Positive 830nm Thermal CTP plate
Plate Thickness
0.15mm to 0.30mm
Resolution
1200dpi
Repeatablity
±5μm(Continuous exposing for 4 times or above on the same plate with a temperature of 23℃ and humidity of 60%)
Interface
USB 2.0
Net Weight
1200 KG
Machine Size(WxLxH)mm
2127x1405x1058
Power Supply
Single phase: 220AC, +6%, -10%, Power consumption: 4KW
Operation Environment
Recommended: 21-25℃, Max. 18-26℃, Humidity: 40-70%
| ECOO T-800F News Thermal CTP Specifications | |
| Model | T-800F News |
| Exposing Method | External drum |
| Imaging System | 64-channel |
| Discrete 830nm laser diode | |
|
Throughput |
60 plates/hour |
| 381mm x 578mm, 1200dpi | |
| Plate Size | Max. 1130mm x 920mm, Min. 300mm x 260mm |
| Media Type | Positive 830nm Thermal CTP plate |
| Plate Thickness | 0.15mm to 0.30mm |
| Resolution | 1200dpi |
| Repeatablity |
±5μm(Continuous exposing for 4 times or above on the same plate with a temperature of 23℃ and humidity of 60%) |
| Interface | USB 2.0 |
| Net Weight | 1200 KG |
| Machine Size(WxLxH)mm | 2127x1405x1058 |
| Power Supply | Single phase: 220AC, +6%, -10%, Power consumption: 4KW |
| Operation Environment | Recommended: 21-25℃, Max. 18-26℃, Humidity: 40-70% |
ฅ^••^ฅ Advantage & Features
1. Speed & Productivity – "A Step Ahead in Speed"
- 60 PPH Verified Speed;
- High-Speed Automated Interface;
- Thermal Imaging Advantage.
2. Newspaper-Grade Quality & Precision – "Precision and Accuracy"
- Optimized 1200 DPI;
- Chemistry-Free or Low-Chemistry Plate Compatibility (if applicable);
- High-Precision Registration System.
3. Unwavering Reliability – "Guardian of the Night Shift"
- 7x24 Design Philosophy;
- Smart Alerts & Remote Diagnostics;
- Simplified Maintenance Design.
4. Intelligence & Ease of Use – "Empowered by Intelligence"
- Seamless Workflow Integration;
- Intuitive Newspaper-Optimized Interface;
- Real-Time Production Dashboard.
ᕦ(･ㅂ･)ᕤ Packaging
Every detail we make will carefully to guarantee good product quality and service to you.
(๑╹◡╹)ﾉ""" Advantages
Our CTP/CTCP Machine with the exterma drum makes CTP Plate fit tighty on the drum, and the technology is better and advanced, making you maintain it easily.
CTP/CTCP Machine replaces the traditional exposure method, which eliminates the occurrence of dirty spots and sun-out in the traditional exposure process so that you can reduce the waste of plates caused by errors in the printing process. And make your image CTP/CTCP Plate more convenient and faster.
After using CTP/CTCP Machine you don't need to buy the traditional film, no film expenses, so that you can save production costs.
A single operator can use CTP/CTCP Machine to complete all the plate-making and plate-washing work by operating the computer, which saving you labor costs.
Our CTP/CTCP Machine supplies our customers three-year warranty, including any spare parts damaged and free replacement to make sure you can use our CTP/CTCP Machine with confidence, no guality concerns.
We will provide the installation site instruction manual and assist online due to the epidemic, if you purchase our CTP/CTCP Machine.
In the shipping, strong wooden box transportation to ensure your CTP/CTCP Machine safely.
๑乛◡乛๑ FAQ
Q1: What are your main products ?
A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on. You can get the equipment and consumables all in one and no worry about the after-sales service from our company.
Q2: Where are you ?
A: Our CTP machine factory is in Hangzhou city, which is about 1.5 hours by train from Shanghai.
You are warmly welcome to visit our factory!
Q3: Is there any certification for your CTP plateSetter ?
A: Yes, all our CTP machines have been certified by SGS and CE.
Q4: Can you also supply Workflow and RIP ?
A: Yes, we can provide the Workflow Brainnew and RIP Compose V12.
Q5: What about the installation and after-sales technician support ?
A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users (printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.
These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.
