Positive PS Plate

EcooGraphix PS Plate or conventional analog plate can be used for offset/lithographic commercial and newspaper printing. Unique production technology and high quality raw materials make the plate gain high photosensitive speed, good half-tone dot reproduction and stable performance.

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

EcooGraphix Positive PS Printing Plate

1.Application

2.Characteristic

1)Uniform surface coating and high photosensitive speed.

2)High resolution and higher press run.

3)Precise half-tone dot reproduction.

4)Faster Exposure and good stability.

3.Specification

General Information
Plate Type	Positive PS Plate/ Conventional Analog Plate
Application	Commercial and newspaper printing
Substrate	Electro chemically Grained and Anodized lithographic Aluminum
Aluminum alloy	Standard 1050 Alloy
Gauge	0.15,0.20, 0.25,0.30, 0.40 (mm)
Maximum short grain width	Maximum width 1280 mm
Length of Run	Unbaked: 50000 to 80,000 impressions Baked: Over 100000 impressions

Exposing
Power of light	3000 - 5000 W
Exposure energy	80 - 180 mJ/cm²
Resolution	2 - 98% LPI 200
Photosensitive Wave Length	320 - 405nm
Coating	Green

Developing
Processor	All the kind Brands or Manual
Developer	Any Positive plate developer or our own developer
Processing temperature	20 - 25°C
Developing time	20 - 30 sec

Storage and handling
Safelight	Handle under yellow safelight (UV free)
Shelf Life	12 months under recommended storage conditions
Packaging	Available in all standard formats, including bulk packaging options such as APL packaging
Storage and handling	Stored in a cool and dry environment, away from excessive cold, heat and humidity.
