7Colors Digital Narrow Web Label UV Inkjet Printer

7Colors Digital Narrow Web Label UV Inkjet Printer





Introduction：



   The Label Ultra combines small-format digital printing with personalized full-color inkjet printing(CMYK ,white and optional green, orange and violet), offering high cost-performance and reasonable operating costs.



    Simple, user-friendly printing operations reduce operating costs and generate higher returns. High-speed, full-color printing, flexible substrates, and easy workflow conversion maximize the advantages of digital label printing.



   This professional-grade digital label press, upgraded with a 1200dpi high-definition printhead, meets your ultimate precision needs, helping you stand out in a competitive market.





Key Advantages:



Highly flexible feeding unit, suitable for widths from 110-330mm
Meets printing demands at high speeds of 75m/min.
Tracking sensor enables precise secondary overprinting.
Wide color gamut LED UV ink for vibrant spot colors.
Maximum resolution reaches 1200×1200 dpi.
Automated rewinding system effectively prevents substrate deviation and ensures neat rewinding.

Each printhead has independent control board and network interface.

Fully LED cold light curing unit for energy efficiency and high efficiency.





  Agfa Asanti software workflow system



   Easy to use, Asanti allows you to trace all prepress steps, and smart visualizedoperation interface keeps you updated on current production status.
The latest technology, Asanti adopts the latest Adobe PDF printing engine (APPE),ensuring reliable, high-quality rendering, precise file processing.
Built-in Preflight Module, Automatically checks files at any time to align with printingrequirements.



Auto web guide tension system:

1 For tension adjustment of all media

2 Auto calculate the length of feeding

3 Ultrasonic detect edge of media to avoid media loading twisty

4 Avoid printing image to stretched and twisted

5 Increase the lifespam of engine



Model	Label Ultra 330 HD
Technical specifications
Printing Technology	Piezoelectric Inkjet	Power
Print Method	Roll to Roll, One – Side	Power Supply	380V
Color Configuration	CMYK/ W+CMYK/ W+CMYK+OGV	Power	40kW
Number Of Channels	8	Compressed air
Maximum Speed	75 m/min(CMYK);50 m/min(CMYK+W)	Compressed air	＞6.5MPa
Resolution	1200×1200dpi	Air consumption	＞10L/min
Ink Type	UV Ink	Environment
Curing Method	UV LED	Operation Temperature	20 – 27°C
Media		Operation Humidity	​40 – 70% Relative humidity
Media Width	​110-330mm	System
Maximum Print Width	320mm	Skew Adjustment System
Media Thickness	​50-400 μm
Media Type	PET, BOPP, PE, BOPA, PP, Coated paper, Synthetic paper, Art paper, etc
Maximum Media Roll Diameter	700mm



Inks Consumption:



Packing details:

Box dimension: 245*155*175cm

Box weight Approx.: 2000kgs

Box materials: Wooden
