Digital Label Varnishing Foiling Printing Machine
EcooSpark is the ideal post press digital embellishment machine for digital label printing machine such as HP Indigo,Xeikon,KM or Screen.Reliable performance and perfect effect.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Products Description
Digital Label Varnishing Foiling Printing Machine
EcooSpark is the Digital Roll to Roll Label Sticker Varnishing and Cold Foiling machine,developed and produced by leading OEM factory EcooGraphix in China. The laminating unit and extra corona treatment unit are optional for some special wine paper or PP film materials. Max print width is up to 450mm.
EcooGraphix four core segments: 1) prepress segment all Ctp machines and plates, 2) label printing segment:digital label printing, label enhancement,label finishing , 3) packaging segment: flexo packaging, paper packaging,4) commercial segment.
As the leading OEM digital label equipment factory in China,EcooGraphix has many customers and partners worldwide.
Applications
Wine Labels, Cosmetic Labels, Luxury labels ,Washi Tape ,Stickers ,Medical Labels ,Pouch Packages ,Braille Marks and so on.
Unlimited design ,
Fast setup time,
Automatic varnish ink cleaning ,
Varnish consumption data
Options of laminating or flexo coating
|
EcooGraphix EcooSpark DS288 Digital Label Foil Stamping and Varnishing Machine |
|
|
Model DigiSpark |
|
|
Printing Technology |
UV Piezo DoD-inkjet |
|
Resolution |
up to 1440*360 dpi |
|
Printing speed |
10m/min - 60m/min(depend on polymer layer thickness) |
|
Variable Image system |
PDF, optimized PDF, Optional barcode system |
|
Supported image standards |
PDF,PDF/VT,TIFF, JPEG, BMP & other data base files |
|
Substrates |
Offset, Digital, Plastics, Laminated and coated substrates |
|
Printing image width |
288mm (extendable to 430 mm) |
|
Polymer |
WB-DS-Clear Polymer |
|
Polymer layer thickness |
From 10 up to 180 microns |
|
Ink curing |
Inter UV-LED Pre-curing/Full curing by UV-LED |
|
Unwinder diameter |
Max. 700mm, Core 76mm |
|
Rewinder diameter |
Max. 700mm, Core 76mm |
|
Substrates thickness |
30-400 micro |
|
Substrates width |
330mm |
|
Press with Foil station dimensions (LxHxW) |
3500mmx1900mmx1800mm |
|
Operating environment |
Temperature: 15℃-30℃, Humidity: 40%-80% relative humidity |
|
Electrical requirements |
Voltage: 3x380, ±5% 3 phases +G+N Frequency: 50/60 Hz Current: Avg. 25 Amps in Production |
|
Weight |
2800kg |
Features
1)Full Sets of Mitsubishi servers;
2)HeFeng Corona Treatment;
3)Web guide and Monitoring System: E+L;
4) Full Led-UV curing system;
5) Printing Software: GIS UK;
6)Auto Cleaning System;
7) KM 1024i print head;
8) Multiple sensors for tention control.
Customizable
Company Profile
EcooGraphix is a leading global supplier and OEM factory of digital printing and packaging equipment and supplies. It began in 2010, developing and manufacturing CTP machines and printing plates.
- Our team has 25 years of experience
- EcooSetter CTP machines and Ecoo printing plates have now become globally renowned brands
- Currently, there are over 500 printers worldwide running EcooGraphix CTP and printing plates daily.
- The digital label printing is a new and fast growth .
- Approximately 45 international distributors worldwide collaborate with EcooGraphix.
