Digital Label Varnish Printing and Cold Foiling Machine
video
Digital Label Varnish Printing and Cold Foiling Machine

Digital Label Varnish Printing and Cold Foiling Machine

EcooGraphix Printing Press tilizes the PiezoDOD inkjet print head technology that enables it to print high quality labels at 600*600 DPI native resolution at speeds up to 70m/min and up to 330 mm of print widths, delivering the expectations of a label printer in terms of lowest total cost of ownership and fastest return on investments.

  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service
Product Introduction

Roll To Roll Digital Label Printing Machine For Foil Stamping And Varnish

(For Cold Foil Stamping, 3D Embossing, Spot Varnishing)




Innovation and Intelligent Manufacturing
The label printing market is going through a transaction period where run lengths are becoming shorter and shorter, media costs are increasing, margins are shrinking and fast turnaround time to market is creating huge pressure on label printers. Here EcooGraphix bridges the gap between the end users, the brand owners and the label printers enabling them to print on demand.
EcooGraphix Printing Press tilizes the PiezoDOD inkjet print head technology that enables it to print high quality labels at 600*600 DPI native resolution at speeds up to 70m/min and up to 330 mm of print widths, delivering the expectations of a label printer in terms of lowest total cost of ownership and fastest return on investments.
Digital is the future, so is the Digital press, it comes with the power of printing short to medium runs very effectively and economically, additionally featuring great value of personalization, variable data and security printing in real time production at one go.





Specification



Model EcooSpark
Printing Technology UV Piezo DoD-inkjet
Resolution up to 1080*360 dpi
Printing speed 10m/min - 60m/min(depend on polymer layer thickness)
Variable Image system PDF, optimized PDF, Optional barcode system
Supported image standards PDF,PDF/VT,TIFF, JPEG, BMP & other data base files
Substrates Offset, Digital, Plastics, Laminated and coated substrates
Printing image size Maximum-Width 280mm x Long 10 m
Polymer WB-DS-Clear Polymer
Polymer layer thickness From 10 up to 50 microns
Ink curing Inter UV-LED Pre-curing/Full curing by UV-LED
Unwinder diameter Max. 700mm, Core 76mm
Rewinder diameter Max. 700mm, Core 76mm
Substrates thickness 30-400 micro
Substrates width 330mm
Press with Foil station dimensions (LxHxW) 3500mmx1900mmx1800mm
Operating environment Temperature: 15ºC-30ºC, Humidity: 40%-80% relative humidity
Electrical requirements Voltage: 3x380, ±5% 3 phases +G+N
Frequency: 50/60 Hz
Current: Avg. 25 Amps in Production
Weight 2800kg





2222 -





Application:
Suitable for packaging printing, label printing with foil/varnish printing. See below sample for your reference.



DigiSpark Sample Labels





Features:
Sturdy structure (double wall panel design)
Thick and thin materials, stability, mature platform
High stability
Good material applicability
No heating required
LED UV+water cooling roller
Suitable for ordinary cold foil



High quality-details, sharp edges:
Less heat, higher stability
Patented technology-better detail performance
Multi-process completed at one time
Customizable



DigiSpark workflow



Printing Press advantage




Quality Control
Professional control department which is responsible for all the machines.
Full checking list including mechanical and electrical detection on the machine.
Strict standard for registration and over 24 hours non-stop running on each machine.
Follow the policy of 'One person responsible for one machine' ,'Claim responsibility if machine has assemble problem.



Service
All of our technicians have over 10-20 years experience.
Rich experience in installation, repairing and maintenance overseas.
After-sales staff Whatsapp/Wechat on line 24/7.
Guarantee to provide after-sales service for any machine for whole using life.
