1880m Wide CTP Plate Machine With Inline Punch

T1880 B0 Size Super Large CTP Plate Printing Machine

Application



  The square screen dot printed on the plate, with sharp edge feature and a rectangular-step-shaped distribution of energy, makes the image clearer, 10 times more accurate than 200lpi AM screening and the color saturation is increased by over 21%.



  EcooGraphix VLF(Very Large Format) CTP Machine 1600S Series can be used for A0, B0 paper size Posters or Wall-charts , Large Books, catalogue, yellow pages, packaging processing and plate-making center etc. , with the output speed up to 22 plates per hour.



  The perfect solution for packaging and iron printing companies has the characteristics of labor saving, high stability, and perfect output quality; two different plate models, thermal and UV, can be selected according to needs; automatic plate loading and unloading, making plate making more efficient; cooperation The automatic plate supply equipment, plate processor, and plate collection rack can realize fully automatic operation, and only one person can complete the publishing operation.



Characteristic

Maximum Plate Size: 1,880×1370mm;

Min Plate Size:1030*770mm

256-channel laser  valve head optional;

With square screen imaging technology adopted, reach saturation increasing by 21% and fineness and precision ten times higher than original;

With linear motor high-precision positioning equipped, achieve longer service life and lower operation and maintenance cost for customer.

Specification

Model	T-1600SX	UV-1600SX	T-1600MX	UV-1600MX
Exposing Method	External Drum
Image System	256Channels  Laser  Light Valve Print Head
Output Speed	22 plates/hour	22 plates/hour	19 plates/hour	19 plates/hour
	1470mm  x 1180mm / 2400dpi		1630mm  x 1325mm / 2400dpi
Plate Sizes	Max.1470mm x1180mm; Min. 400mm x 400mm		Max.1680mm x1350mm; Min. 650mm x 550mm
Media Type	Thermal CTP Plate or Non Chemical Plate	UV CTP/CTCP Plate	Thermal CTP Plate or Non Chemical Plate	UV CTP/CTCP Plate
Plate Thickness	0.15mm to 0.30mm or 0.27mm/ 0.40mm(alternative)
Resolution	Standard: dual resolutions 2400dpi and 1200dpi or optional 2540dpi and 1270dpi. Variable high resolution option: maximum up to 10,000dpi at fast scan direction. 12800DPI is available upon requirement
Repeatability	±0.01mm(continuous exposing for 4times or above on the same plate with a temperature of 23℃ and humidity of 60%)
Interface	Optical Fiber
Plate Loading	semi automatic(alternative autoloader system)
Net Weight	1400KGS		1800KGS
Machine Size (WxLxH)mm	2,355×1,910×1,217		2,400×1,760×1,100
Power Supply	3 phase 380V, powr Consumption(peak value):5.5KW
Operation Envronment	recommended temperature:21-25℃;allowed temperature :15-30℃, humidity:<70%RH



Overall Performance Improvement

	New Laser head Technology makes the plate making performance stable.   At the same time, the speed is improved by leaps and bounds.
	Linear motor  In addition to high acceleration, linear motor drive also has extremely stable operation and high positioning Accuracy, providing the guarantee for high precision and accurate printing.
	Motor direct drive Drum The application of direct motor driving drum technology makes our star-up time accelerated and greatly improves productions efficiency.





1.Use light valve device to divide a laser beam generated from single-source laser into 256 channels of small laser beams with even energy and its exposure screen dots are highly consistent.



2. The square screen dot with sharp edge feature makes the image clearer, 10 times more accurate than 200lpi AM screening and the color saturation is increased by over 21%.



3. Higher efficiency, lower loss-Quick plate making with 256 channels of small laser beams, output speed doubled while drum speed only 20%-50% of the conventional.



EcooGraphix CTP Major Strengths and benefits for customers

● Top quality components: most of core components are imported from worldwide leading supplier in USA, Japan and Germany.

● Massive production (600-700 units per year) ensures QC.

● Most completed portfolio available in the market to offer flexible choice for customers: all formats, all laser technology(thermal and UVCTP(ctcp), both manual and automatic, autoloader, individual laser array and laser Valve.

● Modula designs and simple structure and easy use and maintenance (compared with Kodak, Agfa and Screen)Lifetime warranty for all the spare parts in conjunction with EcooGraphix plates.



 The  T1880 B0 size CTP(Computer To Plate) printing machine is directly controlled by computers, uses laser scanning to image, and then develops and fixes it to produce a printing plate that can be directly printed on the machine. Computer-to-plate making uses a digital workflow to directly convert text and images into numbers and directly generate printing plates, eliminating the need for film as a material, the process of manual imposition, and the semi-automatic or fully automatic printing process.
