B1/A1 Offset Book Litho Printing Plate Thermal CTP

A1/B1 Offset Book Printing Thermal CTP



Application

EcooSetter A series are automatic Lithographic Sheetfed Thermal CTP machines, which can be connected with Autoloader , Bridge and Processor.

T800 A series Thermal CTP are for A1 or B1 paper size , Maximum size of plate: 1,163×940mm,with the output speed 16 to 55 plates per hour.









EcooSetter T-800 A Series Online Thermal CTP Machine

Model: EcooSetter T-800A   F/S/E

Laser wavelength: 830nm , Max Plate Size: 1,163×940mm



ECOOSETTER T-800 A Series Thermal CTP Specifications
Model	T-800FA	T-800SA	T-800EA
Exposing Method	External Drum
Imaging Diodes	64-channel	48-channel	32-channel
	Discrete 830nm laser diode
Throughput	28plates/hour	22plates/hour	16plates/hour
	1030mm x 800mm, 2400dpi
Plate Sizes	Max. 1,163×940mm, Min. 300×400mm
Media Type	830nm Thermal CTP Plate, Non Chemical Processless Plate
Plate Thickness	0.14mm to 0.30mm
Resolution	2400dpi(1200dpi optional)
Repeatability	±5μm(continuous exposing for 4times or above on the same plate with a temperature of 23℃ and humidity of 60%)
Interface	USB 2.0
Plate Loading	Automatic
Net Weight	1200KGS
Machine Size	2,127×1,610×1,058 mm( L×W×H )
Power Supply	single phase:220AC,+ 6%,- 10%, power Consumption:4KW
Operation Environment	recommended:21-25℃, Max.18-26℃, humidity:40-70%



Model: EcooSetter T-800(F/S/E)XA

256CH Laser Valve , Speed: 55/45/35 PPH

ECOOSETTER T-800 XA Series Thermal CTP Specifications
Model	T-800FXA	T-800SXA	T-800EXA
Exposing Method	External Drum
Imaging Laser Head	256Channels Laser Valve
Throughput Speed	55plates/hour	45plates/hour	35plates/hour
	1030mm x 800mm, 2400dpi
Plate Sizes	Max. 1,163×940mm, Min. 300×400mm
Media Type	830nm Thermal CTP Plate, Non Chemical Processless Plate
Plate Thickness	0.14mm to 0.30mm
Resolution	2400dpi(2540dpi, 1200dpi optional)
Repeatability	±5μm(continuous exposing for 4times or above on the same plate with a temperature of 23℃ and humidity of 60%)
Interface	USB 2.0
Plate Loading	Automatic
Net Weight	1200KGS
Machine Size	2,127×1,610×1,058 mm( L×W×H )
Power Supply	single phase:220AC,+ 6%,- 10%, power Consumption:4KW
Operation  Environment	recommended:21-25℃, Max.18-26℃, humidity:40-70%











Buyer need to prepare before installation:



1. Customer should prepare tools:

Lift truck and driver: to unload the machine, truck fork should be 1.5Ton or above capacity, 1.2m or longer arm;



2. CTP working environment:

Temperature: 15℃-30℃ (an air-conditioner is recommended)

Humidity: RH10%-70%, Non-condensing

Atmosphere: No smoke, No corrosive gases, Ash<0.1mg/M3.

Lighting: Natural illumination, no direct sunlight

Floor: The floor should bear the pressure of 500kg/m2. Anti-static floor or tile floor.

Ventilation: natural ventilation

Thermometer and hygrometer (pointer type or digital type) should be kept in the center of the room.



3. Power supply:

CTP Ecoosetter Series: single phase, independently grounded, less than 3Ω; 50/60Hz, 4KVA.

An online uninterrupted power supply(UPS) unit is required, and the battery should be able to sustain at least 5 minute alone.



4. Other equipment customer should prepare:

Computer: one computer is required to control the CTP. Configuration: I3 or above, 500G or above, Windows 7/8/10, English operation system (US);

Air: separated air-compressor or central air. ≥0.8Mpa, ≥175L/min. If separated air-compressor, the air tank should be ≥30L.

Processor

Plate and chemicals

Plate dot measurement tools (Replate or IC plate)



5. Workflow

RIP: customer should have workflow to generate 1-bit-tiff file. Ecoosetter CTP has program to receive 1-bit-tiff file.



Installation Cases of EcooGraphix T800A Online System
